The all-in-one Grundfos Pressure Manager is an intelligent pump controller that turns on your pump in accordance with consumption in domestic water supply and booster systems. The Pressure Manager is suitable for toilets, washing machines and outside taps.
This state-of-the-art product offers benefits from innovative Grundfos features including functionality, system integration, plug-and-pump convenience and easy of use. The Pressure Manager offers a choice of two excellent models: the PM1 for basic flexibility and the PM2 for all-round control.
The PM1 is suitable for applications where start/stop of the pump according to consumption is required. It is the basic flexibility solution, offering pump start at 1.5 or 2.2 bar.
The PM2 is the all-round control solution, offering adjustable pump start at 1.5 to 5 bar. This enables customization to different types of installation and desired comfort levels. The start pressure is set inside the unit, whereas current pressure is read on the intuitive LED display on the front of the Pressure Manager.
Need a pump sized by an expert? Click on the form below -
Description |
PM1 - 1.5 BAR / 1" M Connections / 1 x 230 Volt 50/60Hz |
PM1 - 2.2 BAR / 1" M Connections / 1 x 230 Volt 50/60Hz |
PM2 - 1.5-5 BAR / 1" M Connections / 1 x 230 Volt 50/60Hz |
Feature | PM 1 | PM 2 |
Power-on indication | ● | ● |
Pump running indication | ● | ● |
Alarm indication | ● | ● |
Dry-running protection | ● | ● |
Free position in installation | ● | ● |
Suitable for generator supply | ● | ● |
Rotary outlet connection | ● | ● |
Integrated non-return valve | ● | ● |
Cycling alarm | ● | ● |
Integrated pressure sensor from Grundfos Direct Sensors | ● | |
Adjustable start pressure | ● | |
Start/stop with 1 bar differential pressure | ● | |
Automatic restarting after dry running | ● | |
Maximum continuous operating time (30 minutes) (safety) | ● | |
Pressure indication | ● | |
Internal pressure tank | ● |
